Technical specifications for 22B-V5P0F104

Manufacturer: Allen-Bradley Part Number: 22B-V5P0F104

The Allen-Bradley/Rockwell Automation 22B-V5P0F104 drive is an adjustable frequency drive from the PowerFlex 40 series. It uses its adjustable frequency to adjust the speed and torque of a motor in an Allen-Bradley PLC system. The 22B-V5P0F104 adjustable frequency drive operates with an output current rating of 5 Amps and a 1-phase input voltage rating of 120 Volts AC. It can…

12-month warranty
New Surplus
Available on request

Availability & pricing

Condition	Price	Stock / lead time	Action
New Surplus	On request	Available on request

Technical specifications

Manufacturer	Rockwell Automation
Brand	Allen-Bradley
Part Number/Catalog No.	22B-V5P0F104
Product Line Powerflex	40
Voltage	120AC Volts
Enclosure	Flange Mount - IP20, NEMA/UL Type Open
HP	1 Horsepower
Amperage	5.0 A
Phase	1 Phase
Filter	No CE Compliant Filter
Communication	RS-485
Input	Type Keypad

Description

The Allen-Bradley/Rockwell Automation 22B-V5P0F104 drive is an adjustable frequency drive from the PowerFlex 40 series. It uses its adjustable frequency to adjust the speed and torque of a motor in an Allen-Bradley PLC system. The 22B-V5P0F104 adjustable frequency drive operates with an output current rating of 5 Amps and a 1-phase input voltage rating of 120 Volts AC. It can be flange mounted inside an enclosure with an IP 20, IP 40, IP 54, or IP 65 environmental protection rating. The 22B-V5P0F104 adjustable frequency drive does not come with a filter.
Technical specifications for 22B-V5P0F104
Manufacturer Rockwell Automation
Brand Allen-Bradley
Part Number/Catalog No. 22B-V5P0F104
Product Line Powerflex 40
Voltage 120AC Volts
Enclosure Flange Mount – IP20, NEMA/UL Type Open
HP 1 Horsepower
Amperage 5.0 A
Phase 1 Phase
Filter No CE Compliant Filter
Communication RS-485
Input Type Keypad
This performance-improving PowerFlex 40 Low Voltage AC Drive Module motor control by Allen Bradley provides OEM (Original Equipment Manufacturer) and a Sensorless Vector Control feature, designed to meet slow torque. The slow torque of this module, the 22B-V5P0F104, improves application performance.

This module, part of the Allen Bradley PowerFlex 40 Low Voltage AC Drive Module series has an uncomplicated programming structure, making it easy to control as well as install for a variety of applications.

The 22B-V5P0F104 module comes with a built-in Integral Keypad. It operates on a 50 or 60 Hertz frequency with a voltage rating of 100 or 120 Volts AC. It has an IP20 Flange Mount enclosure, the front being an IP20 NEMA/UL Type Open with an IP40/54/65 NEMA/UL Type 1/12/4/4X Back/Heatsink.

This module can operate at temperatures between 0 degrees Celsius (32 degrees Fahrenheit) and 60 degrees Celsius (140 degrees Fahrenheit). When not being operated, this module should be kept in temperatures between a minimum of -40 degrees Celsius and a maximum of 85 degrees Celsius (-40 and 185 degrees Fahrenheit).

The 22B-V5P0F104 follows several EMC (ElectroMagnetic Compatibility) standards, including Part 2 of the Generic Emission Standard (Industrial Environment), both EN 50081-2 EMC and EN 50082-2 EMC.

Weighing in at 4.53 kilograms, this unit’s compact design measures approximately 250.0 x 244.0 x 94.3 millimeters.
