Technical specifications for 140HLI34000

Description

Modicon Quantum – latch/interrupt module – 16 I – fast isolated
140HLI34000

Main
Range of Product
Modicon Quantum automation platform
Product or Component Type
Latch/interrupt module
Complementary
Number of inputs
16
Discrete input type
Fast isolated
Absolute maximum input
30 V DC
Voltage state 0 guaranteed
-3…5 V
Voltage state 1 guaranteed
15…30 V
Current state 0 guaranteed
2…8 mA
Current state 1 guaranteed
<= 0.5 mA
Response time
130 µs Off-On
30 µs On-Off
Reverse polarity protection
Internal in 30 V
Isolation between channels
500 V 60 s AC
Isolation between channels and bus
1780 V 60 s AC
Bus current requirement
400 mA
Power dissipation
2.0 W + (0.3 x number of points on)
Mounting Support
Backplane for local architecture
Marking
CE
Module format
Standard
Environment
Resistance to electrostatic discharge
4 kV contact IEC 801-2
8 kV on air IEC 801-2
Resistance to electromagnetic fields
9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3
Ambient Air Temperature for Operation
32…140 °F (0…60 °C)
Ambient Air Temperature for Storage
-40…185 °F (-40…85 °C)
Relative Humidity
95 % without condensation
Operating altitude
<= 16404.2 ft (5000 m)
Standards
UL 508
Product Certifications
DNV
GOST
CSA Class 1 Division 2
UL
FM Class 1 Division 2
C-tick
Ordering and shipping details
Category
18155-QUANTUM I/O & POWER SUPPLIES
Discount Schedule
PC21
GTIN
3595861136113
Returnability
No
Country of origin
FR
Packing Units
Unit Type of Package 1
PCE
Nbr. of units in pkg.
1
Package 1 Height
1.77 in (4.500 cm)
Package 1 Width
6.50 in (16.500 cm)
Package 1 Length
12.40 in (31.500 cm)
Package weight(Lbs)
14.392 oz (408.000 g)
Unit Type of Package 2
S02
Number of Units in Package 2
2
Package 2 Height
5.91 in (15.000 cm)
Package 2 Width
11.81 in (30.000 cm)
Package 2 Length
15.75 in (40.000 cm)
Package 2 Weight
28.783 oz (816.000 g)
