FANUC · FANUC Series 30i-A · Communication Modules

Technical specifications for A02B-0303-D500

Manufacturer: FANUC Part Number: A02B-0303-D500

Official FANUC identity (per B-63945EN/02 Maintenance/Connection Manual): 10.4-inch color LCD display unit (no touch panel). 10.4-inch color LCD display unit without touch panel for FANUC Series 30i/31i/32i CNC controls.

12-month warranty
New Surplus
Available on request

Availability & pricing

Condition	Price	Stock / lead time	Action
New Surplus	On request	Available on request

Technical specifications

Input	no touch panel (supplier-reported (Industrial Automation Co., FanucWorld))
Type: LCD	display unit

Description

Model: A02B-0303-D500
Brand: FANUC
Series: FANUC Series 30i-A
Official FANUC identity (per B-63945EN/02 Maintenance/Connection Manual): 10.4-inch color LCD display unit (no touch panel).

10.4-inch color LCD display unit without touch panel for FANUC Series 30i/31i/32i CNC controls.

── Hardware ──
10.4-inch color LCD display without touch panel for 30i-A series (multi-source consensus; FanucWorld + aftermarket listings)
Input: no touch panel (supplier-reported (Industrial Automation Co., FanucWorld))
Type: LCD display unit

Official BOM listing per FANUC B-63945EN/02 Maintenance Manual, p.200; hardware identity corroborated
── Communication ──
Not applicable (passive component; no built-in communication ports)

── Electrical ──
Supply voltage: 24 VDC (external supply to stand-alone LCD unit; manual-cited; B-63943EN/02 §5.2.1, p.87)
Heat output: 13 W (stand-alone 10.4″ display unit; manual-cited; B-63943EN/02 Table 3.4.2(a), p.58)

── Environmental ──
Operating ambient temperature: 0 to 55 °C (official per B-63945EN/02 Maintenance Manual §5.10 Environmental Conditions, p.329/printed 356)
Storage/transport ambient temperature: −20 to 60 °C (official per B-63945EN/02 Maintenance Manual §5.10 Environmental Conditions, p.329/printed 356)
Relative humidity: 75%RH or less normal; up to 95%RH for short periods (≤1 month), no condensation (official per B-63945EN/02 Maintenance Manual §5.10 Environmental Conditions, p.329/printed 356)

── Physical ──
Dimensions (H×W×D): Not published for this specific order code (10.4-inch color LCD display (no touch); LCD-mounted basic unit dimensions not applicable)
Weight: 2.0 kg (stand-alone 10.4″ color LCD display unit; manual-cited; B-63943EN/02 Fig. U8, p.379)

── Lifecycle ──
Legacy (Series 30i-A/31i-A/32i-A generation; superseded by Series 30i/31i/32i-B) (Last verified: 2026-09)

Frequently asked questions

What is the A02B-0303-D500?

FANUC A02B-0303-D500 is an industrial automation component we supply from surplus and refurbished stock. Confirm the exact configuration, condition and lead time with our team before purchase.

Is the A02B-0303-D500 in stock, and what is the lead time?

We list the A02B-0303-D500 as in stock in New Surplus condition. Request a quote for current availability, pricing and confirmed lead time — most items ship within 1–3 business days.

Do you provide a datasheet for the A02B-0303-D500?

Where available, the product page links the original manufacturer datasheet (PDF). Use the request-a-quote form to receive the full documentation pack and compliance information.

Can the A02B-0303-D500 be cross-referenced to an equivalent?

Many automation parts have equivalents or legacy replacements. Send us the A02B-0303-D500 together with your application details and we will confirm compatibility and alternatives.
