FANUC · FANUC Series 16/18 CNC · Communication Modules

Technical specifications for A02B-0120-K301

Manufacturer: FANUC Part Number: A02B-0120-K301

Connector kit (20-pin ribbon cable connector) for FANUC Series 16/18 CNC.

12-month warranty
New Surplus
Available on request

Availability & pricing

Condition	Price	Stock / lead time	Action
New Surplus	On request	Available on request

Technical specifications

Power	consumption: Not applicable (passive component; no independent power consumption)
Operating	temperature: Not applicable (passive component; rating follows host CNC)
Storage	temperature: Not applicable (passive component; rating follows host CNC)
Relative	humidity: Not applicable (passive component; rating follows host CNC)

Description

Model: A02B-0120-K301
Brand: FANUC
Series: FANUC Series 16/18 CNC

Connector kit (20-pin ribbon cable connector) for FANUC Series 16/18 CNC.

── Hardware ──
Connector kit: Honda PCR-E20FS (connector) + PCR-V20LA (case), soldering type, for operators panel depth 80 mm min. (manual-cited; GFZ-63523EN/03 §9.13.3.10, p.380, connector on cable side specifications)

── Communication ──
Not applicable (passive component; no built-in communication ports)

── Electrical ──
Supply voltage: Not applicable (passive component; cable/connector/fuse/memory card; powered by host system)
Power consumption: Not applicable (passive component; no independent power consumption)

── Environmental ──
Operating temperature: Not applicable (passive component; rating follows host CNC)
Storage temperature: Not applicable (passive component; rating follows host CNC)
Relative humidity: Not applicable (passive component; rating follows host CNC)

── Physical ──
Dimensions (H×W×D): Not applicable (passive connector kit; no manufacturer-published outline dimensions)
Weight: ~0.03 kg (supplier-reported; family-level reference; not confirmed for this specific order code; per DO Supply K321 connector kit)

── Lifecycle ──
Legacy (spare-part connector kit for FANUC Series 16/18 CNC; Series 16/18 is a legacy control generation) (Last verified: 2026-09)

Frequently asked questions

What is the A02B-0120-K301?

FANUC A02B-0120-K301 is an industrial automation component we supply from surplus and refurbished stock. Confirm the exact configuration, condition and lead time with our team before purchase.

Is the A02B-0120-K301 in stock, and what is the lead time?

We list the A02B-0120-K301 as in stock in New Surplus condition. Request a quote for current availability, pricing and confirmed lead time — most items ship within 1–3 business days.

Do you provide a datasheet for the A02B-0120-K301?

Where available, the product page links the original manufacturer datasheet (PDF). Use the request-a-quote form to receive the full documentation pack and compliance information.

Can the A02B-0120-K301 be cross-referenced to an equivalent?

Many automation parts have equivalents or legacy replacements. Send us the A02B-0120-K301 together with your application details and we will confirm compatibility and alternatives.
