Technical specifications for 22D-E019F104

Description

The 22D-E019F104 adjustable frequency drive is an Allen-Bradley/Rockwell Automation PowerFlex 40P series adjustable frequency drive. It can control the torque and speed of compatible variable speed motors in Allen-Bradley programmable logic controller or PLC systems. The 22D-E019F104 adjustable frequency drive operates with a 3-phase input voltage rating of 600 Volts AC at 50 to 60 Hertz. It can be flange-mounted inside an Technical specifications for 22D-E019F104
Manufacturer Rockwell Automation
Brand Allen-Bradley
Part Number/Catalog No. 22D-E019F104
Product Line Powerflex 40P
Amperage 19.0 A
Phase Three-Phase
Enclosure Open NEMA Type -Flange Mount (IP20)
Input Power 600 Volts AC
Horsepower 15 Horsepower
Filter No CE Compliant Filter
Type Standard
Frame Size C Description
The Allen-Bradley 22D-E019F104 is an AC adjustable frequency drive that belongs to the PowerFlex 40P series. This PowerFlex 40P series offers an improved speed regulation and a basic position control respecting the previous series. The Allen-Bradley 22D-E019F104 PowerFlex 40P AC adjustable frequency drive operates at a voltage rating of 600 Volts AC, an output current of 160 to 600 Volts, and a rating of 19 Amps, 11 kW (15 HP) The Allen-Bradley 22D-E019F104 PowerFlex 40P AC adjustable frequency drive features a NEMA type 1 enclosure that protects the whole unit from particles that could build up and affect the functioning of the unit. The unit should not be exposed to a corrosive atmosphere and when in storage, it can withstand a temperature range of -40 to 85 degrees Celsius and a relative humidity of 95%. It can operate at 1000 meters maximum without derating.

To guarantee reliable and smooth operations while the unit is operating at its maximum rating, it should not be located too far from the motor due to reflected wave phenomena. Additionally, a clearance space is required between this unit and other units around in order to allow a proper cooling convection mechanism. The Allen-Bradley 22D-E019F104 PowerFlex 40P AC adjustable frequency drive has an increased power loss ride through and other important features such as a slip calculation, a standard traverse, and P-jump, a speed ratio over communication commands, synchronized input ramps, and a configurable dual channel incremental encoder. This unit can also operate as an independent position controller for a single time, annulling this way the need for multiple sensors. The control mechanism of this unit is by the means of a sinusoidal PWM, Volts/Hertz, and sensorless Vector.
