Technical specifications for 330708-00-25-90-02-00

Description

“Manufacturer : Bently Nevada
Product No. :330708-00-25-90-02-00
Product type : 3300 XL 11 mm Proximity Probes
Made in U.S.A

330708 = 3300 XL 11 mm Probe, 5/8-18 UNF thread, without armor
Unthreaded Length Option : 00=0 in
Overall Case Length Option :25= 2.5 in
Total Length Option :90=9.0 meters (29.5 feet)
Connector and Cable-Type Option :02 = Miniature coaxial ClickLoc
connector, standard cable
Agency Approval Option :00 = Not required
Probe Tip Material: Polyphenylene sulfide (PPS).
Probe Case Material: AISI 304 stainless steel (SST).
Probe Cable Specifications: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated probe cable in the following total probe lengths: 1, 5 or 9 metres.
Operating and Storage Temperature: -51°C to +177°C (-60°F to +351°F)
Probe Pressure: 3300 XL probes are designed to seal differential pressure between the probe tip and case. The probe sealing material consists of a Viton* O-ring. Probes are not pressure tested prior to shipment. Contact our custom design department if you require a test of the pressure seal for your application
Shipping weight : 0.17 Kg

Probe dc Resistance
Probe
Length (m) 9.0
Resistance from the Center
Conductor to the Outer
Conductor (RPROBE) (ohms) 8.5 ± 1.1

Probe Case Thread 5/8-18
Maximum Length of Thread Engagement 0.938 in

Probe Case Torque 1/2-20 and 5/8-
18 probe cases
Maximum Rated 45.2 N•m (400 in•lb)
Recommended
15.2 N•m
(133 in•lb)

Probe Tip
Material Polyphenylene sulfide (PPS).
Probe Case
Material AISI 304 stainless steel (SST).
Probe Cable
Specification
75 Ω triaxial, fluoroethylene
propylene (FEP) insulated
probe cable in the following
total probe lengths: 1, 5 or 9
meters.

Connector-to-connector torque
Recommended
torque Finger tight
Maximum
torque 0.565 N•m (5 in•lb)
Minimum Bend
Radius (with or
without SST
armor)
25.4 mm (1.0 in)

Probe Case Thread M16x1.5
Maximum Length of Thread Engagement 24 mm

Probe Case Thread M14x1.5
Maximum Length of Thread Engagement 21 mm

Probe Temperature Range
Operating and
Storage
Temperature
-52°C to +177°C (-62°F to
+351°F)
Exposing the probe to temperatures
below -34°C (30°F) may cause
premature failure of the pressure
seal.
“
